Keypad for 4 Key Q-Logic NE Wheelchair Joystick

Restore the functionality and appearance of your wheelchair joystick with this replacement keypad for the Q-Logic NE 4-Button Joystick. Designed to replace a worn, damaged, or unresponsive keypad, this adhesive-backed replacement installs directly onto the existing joystick faceplate.

Product Features

• Replacement keypad for the Q-Logic NE 4-button joystick
• Compatible with Pride joystick model CTLDC1554
• Adhesive-backed design for simple installation
• Replaces worn, damaged, or non-responsive keypads

Fitment Notes:
Please compare your existing keypad to the product photos and specifications to ensure compatibility before ordering.

Keypad Replacement Instructions:

1. Turn off the wheelchair power.
2. Disconnect the joystick cable by pulling back the gray collar.
3. Gently pry the existing keypad off the controller.
4. Inspect the joystick, contacts, and housing for damage or corrosion.
5. Clean all old adhesive from the faceplate using an alcohol prep pad, including around edges and cutouts.
6. Allow the faceplate to dry completely for about 10 minutes, then verify all adhesive residue has been removed.
7. Remove the protective backing from the new keypad.
8. Carefully align the new keypad with the joystick faceplate. Once applied, it cannot be repositioned.
9. Press the keypad into place from the bottom upward, ensuring a secure bond.
10. Check that the keypad is fully seated with no wrinkles, ripples, or air pockets.
11. Reconnect the joystick cable.
12. Power on the wheelchair and test all joystick functions.
13. If the joystick still does not operate correctly, the joystick itself may be faulty.

CTL152799 KIT152913 Overlay Keypad for 4 Key Q-Logic NE Wheelchair Joystick
